Triumph Tiger Explorer specs revealed

Full specs for all six new Tiger Explorer models released

Simon Greenacre

Updated: 10 May 2024

WE already know there are six variations of the new Triumph Tiger Explorer but with the launch taking place this week, Triumph has just released some more details about the bike, along with specs for each model.

As a reminder, the six variations are: XC, XCx, XCa, XR, XRx and XRt. Each is powered by the same 1215cc three-cylinder engine with shaft drive. Power is at a claimed 139ps at 9,300rpm, with 90.7lb/ft claimed torque at 6,200rpm. Triumph also says the 2016 Tiger Explorer has 5% better fuel economy than the model is replaces.

In terms of technology, the Tiger Explorer family includes cornering ABS and traction control, five riding modes (road, rain, off-road, sport & custom) and a hill hold function. It’s also got an inertial measurement unit which measures pitch, yaw, roll and acceleration across three-planes (vertical, lateral and longitudinal).

The XCX, XCA, XRX, XRT models feature WP semi-active suspension with auto-levelling rear preload and a torque assist clutch.

The XRx and XCx models will have a low seat option.

There’s no word on price yet, but we’re riding the bike this week and will let you know as soon as we find out. Our first ride review will be up soon.

Here are the specs from Triumph:

.	Tiger Explorer XR	Tiger Explorer XRX	Tiger Explorer XRT	Tiger Explorer XC	Tiger Explorer XCX	Tiger Explorer XCA
POWER	139PS @ 9,300rpm	139PS @ 9,300rpm	139PS @ 9,300rpm	139PS @ 9,300rpm	139PS @ 9,300rpm	139PS @ 9,300rpm
TORQUE	123Nm @ 6,200rpm	123Nm @ 6,200rpm	123Nm @ 6,200rpm	123Nm @ 6,200rpm	123Nm @ 6,200rpm	123Nm @ 6,200rpm
ENGINE TYPE	Liquid-cooled, in-line, 3 cylinder	Liquid-cooled, in-line, 3 cylinder	Liquid-cooled, in-line, 3 cylinder	Liquid-cooled, in-line, 3 cylinder	Liquid-cooled, in-line, 3 cylinder	Liquid-cooled, in-line, 3 cylinder
ENGINE SIZE	1,215cc	1,215cc	1,215cc	1,215cc	1,215cc	1,215cc
SEAT HEIGHT	837/857mm	837/857mm	837/857mm	837/857mm	837/857mm	837/857mm
SEAT HEIGHT	837/857mm	(805 – 785 mm low seat version)	837/857mm	837/857mm	(805 – 785 mm low seat version)	837/857mm
FRONT SUSPENSION	48mm, WP USD fork, adjustable rebound and compression damping	48mm, WP USD fork, electrically adjustable in rebound and compression damping	48mm, WP USD fork, electrically adjustable in rebound and compression damping	48mm, WP USD fork, adjustable rebound and compression damping	48mm, WP USD fork, electrically adjustable in rebound and compression damping	48mm, WP USD fork, electrically adjustable in rebound and compression damping
REAR SUSPENSION	WP monoshock, adjustable in pre-load and rebound damping. Cast aluminium single sided swingarm	Semi-active WP monoshock with automatic preload adjustment.	Semi-active WP monoshock with automatic preload adjustment.	WP monoshock, adjustable in pre-load and rebound damping. Cast aluminium single sided swingarm	Semi-active WP monoshock with automatic preload adjustment.	Semi-active WP monoshock with automatic preload adjustment.
REAR SUSPENSION		Cast aluminium single sided swingarm	Cast aluminium single sided swingarm		Cast aluminium single sided swingarm	Cast aluminium single sided swingarm
FRONT BRAKES	Dual 305mm discs, Brembo Monobloc 4-piston radial calipers	Dual 305mm discs, Brembo Monobloc 4-piston radial calipers	Dual 305mm discs, Brembo Monobloc 4-piston radial calipers	Dual 305mm discs, Brembo Monobloc 4-piston radial calipers	Dual 305mm discs, Brembo Monobloc 4-piston radial calipers	Dual 305mm discs, Brembo Monobloc 4-piston radial calipers
REAR BRAKES	Single 282mm disc, Nissin 2-piston sliding caliper	Single 282mm disc, Nissin 2-piston sliding caliper	Single 282mm disc, Nissin 2-piston sliding caliper	Single 282mm disc, Nissin 2-piston sliding caliper	Single 282mm disc, Nissin 2-piston sliding caliper	Single 282mm disc, Nissin 2-piston sliding caliper
TANK CAPACITY	20L	20L	20L	20L	20L	20L
DRY WEIGHT	244kg	246kg (244kg Low seat version)	254kg	246 kg	253kg (251kg Low seat version)	258kg
COLOURS	Jet Black	Jet Black	Crystal White	Jet Black	Jet Black	Crystal White
	Crystal White	Crystal White	Lucerne Blue	Crystal White	Crystal White	Lucerne Blue
	Phantom Black	Lucerne Blue	Cranberry Red	Phantom Black	Lucerne Blue	Matt Khaki Green
STANDARD EQUIPMENT	· ABS and Traction Control	Additional to the XR:	Additional to XRX:	· ABS and Traction Control	Additional to the XC:

	· ‘Road’ and ‘Rain’ Riding Modes	· Cornering optimised ABS and Traction Control	· ‘Sport’ and ‘Rider’ adjustable Riding Modes	· ‘Road’ and ‘Rain’ Riding Modes	· Cornering optimised ABS and Traction Control

	· Electrically adjustable screen	· ‘Off-road’ Riding Mode	· Hill Hold control	· Electrically adjustable screen	· ‘Off-road’ Riding Modes

	· Centre stand	· Cruise Control	· Electrically adjustable Touring screen	· Centre stand	· Cruise Control

	· Immobiliser	· Inertial Measurement Unit	· Tyre Pressure Monitoring System	· Immobiliser	· Inertial Measurement Unit

	· 12V power socket	· Triumph Semi Active Suspension	· Pannier rails for aluminium panniers	· 12V power socket	· Triumph Semi Active Suspension

	· USB power socket	· Self-cancelling LED Indicators	· Heated rider and passenger seat	· USB power socket	· Self-cancelling LED Indicators

	· On-board computer	· Hand guards	Engine protection bars	· On-board computer	· Hand guards

	Cast wheels	· Additional 12v power socket	· Sump guard	· Additional 12v power socket

	· Heated grips	Spoke wheels for tubeless tyres	· Heated grips
	Advanced on-board computer
	· Advanced on-board computer

	· Aluminium sump guard

	· Stainless radiator guard
